Performance @27ºC, Vacuum |
Performance @50ºC, Dry N2 |
Cold Side |
Hot Side |
Height |
||||||||||
|
TEC TYPE |
dTmax |
Qmax |
Imax |
Umax |
ACR |
dTmax |
Qmax |
Imax |
Umax |
ACR |
A |
B |
C |
D |
H |
|
|
K |
W |
A |
V |
Ohm |
K |
W |
A |
V |
Ohm |
mm |
mm |
mm |
mm |
mm |
|
4MC04-115-xx |
|||||||||||||||
|
4MC04-115-05 |
125 |
0.6 |
0.9 |
8.2 |
7.56 |
125 |
0.6 |
1.0 |
9.3 |
8.44 |
2.4 |
2.4 |
9.6 |
9.6 |
4.9 |
|
4MC04-115-08 |
125 |
0.4 |
0.6 |
8.2 |
11.99 |
119 |
0.4 |
0.6 |
9.5 |
13.40 |
2.4 |
2.4 |
9.6 |
9.6 |
6.1 |
|
4MC04-115-10 |
125 |
0.3 |
0.5 |
8.2 |
14.94 |
115 |
0.3 |
0.5 |
9.6 |
16.70 |
2.4 |
2.4 |
9.6 |
9.6 |
6.9 |
|
4MC04-115-12 |
125 |
0.2 |
0.4 |
8.2 |
17.89 |
111 |
0.3 |
0.4 |
9.7 |
20.00 |
2.4 |
2.4 |
9.6 |
9.6 |
7.7 |
|
4MC04-115-15 |
124 |
0.2 |
0.3 |
8.3 |
22.31 |
106 |
0.2 |
0.4 |
9.8 |
24.96 |
2.4 |
2.4 |
9.6 |
9.6 |
8.9 |
|
4MC04-117-xx |
|||||||||||||||
|
4MC04-117-03 |
122 |
0.9 |
1.5 |
8.2 |
4.65 |
126 |
1.0 |
1.6 |
9.3 |
5.18 |
2.4 |
2.4 |
9.6 |
12.2 |
4.1 |
|
4MC04-117-05 |
125 |
0.6 |
0.9 |
8.3 |
7.63 |
125 |
0.6 |
1.0 |
9.5 |
8.52 |
2.4 |
2.4 |
9.6 |
12.2 |
4.9 |
|
4MC04-117-08 |
126 |
0.4 |
0.6 |
8.3 |
12.09 |
119 |
0.4 |
0.6 |
9.6 |
13.51 |
2.4 |
2.4 |
9.6 |
12.2 |
6.1 |
|
4MC04-117-10 |
126 |
0.3 |
0.5 |
8.3 |
15.07 |
115 |
0.3 |
0.5 |
9.7 |
16.85 |
2.4 |
2.4 |
9.6 |
12.2 |
6.9 |
|
4MC04-117-12 |
125 |
0.2 |
0.4 |
8.4 |
18.04 |
111 |
0.3 |
0.4 |
9.7 |
20.18 |
2.4 |
2.4 |
9.6 |
12.2 |
7.7 |
|
4MC04-117-15 |
125 |
0.2 |
0.3 |
8.4 |
22.51 |
106 |
0.2 |
0.4 |
9.9 |
25.18 |
2.4 |
2.4 |
9.6 |
12.2 |
8.9 |
STANDARD MC04 SERIES 4-STAGE THERMOELECTRIC COOLERS AVAILABLE
4MC04 TE COOLERS ADVANTAGES
4MC04 TE COOLERS KEY FEATURES
◻︎ "Classic" regular assembly technology
◻ Dimensions from 2x4mm2 up to 4x4mm2
◻ Solutions with round cold side are possible
◻ Wide range of manufacturing options available
◻ High-quality bulk BiTe material
◻ Accurate steam soldering technology
◻ RoHS compliant TE Coolers by default
◻ Telcordia GR-468 qualified TECs
4MC04
Four-stage
TE Coolers
Thermoelectric coolers of MC04 Series represent our solid and reliable "classic" TECs. MC04 Series is based on regular TEC assembly technology with ~150elements/cm2 pellets placement density. MC04 Series is technologically close to MC06 Series, but consists of smaller TECs, cause it's based on smaller pellets cross-section. 4-stage thermoelectric coolers in MC04 Series have cold side dimensions from 2.0 x 4.0mm2 up to 4.0 x 4.0mm2 . MC04 TEC Series is universal by application focus with many surface options and terminal connection configurations. All thermoelectric coolers are assembled using RoHS compliant Sn-Sb solder with a melting temperature Tmelt=230ºC. Thermoelectric coolers of MC04 Series meet Telcordia GR-486 standard requirements. Wide range of TEC manufacturing options is available. The standard and most common 4-stage types from our MC04 Series are listed in the table below. Detailed TEC drawings, 3D models, performance plots and estimations for particular application conditions are provided by request.
