Performance @27ºC, Vacuum |
Performance @50ºC, Dry N2 |
Cold Side |
Hot Side |
Height |
||||||||||
|
TEC TYPE |
dTmax |
Qmax |
Imax |
Umax |
ACR |
dTmax |
Qmax |
Imax |
Umax |
ACR |
A |
B |
C |
D |
H |
|
|
K |
W |
A |
V |
Ohm |
K |
W |
A |
V |
Ohm |
mm |
mm |
mm |
mm |
mm |
|
2MDX10-022-xxAN |
|||||||||||||||
|
2MDX10-022-0510AN |
92 |
4.0 |
6.6 |
2.0 |
0.25 |
98 |
4.5 |
6.6 |
2.2 |
0.28 |
7.4 |
7.4 |
7.4 |
7.4 |
3.2 |
|
2MDX10-022-0816AN |
94 |
2.6 |
4.2 |
1.9 |
0.39 |
98 |
3.0 |
4.3 |
2.2 |
0.43 |
7.4 |
7.4 |
7.4 |
7.4 |
4.2 |
|
2MDX10-022-1020AN |
95 |
2.1 |
3.5 |
2.0 |
0.48 |
98 |
2.4 |
3.5 |
2.2 |
0.53 |
7.4 |
7.4 |
7.4 |
7.4 |
4.7 |
|
2MDX10-042-xxAN |
|||||||||||||||
|
2MDX10-042-0510AN |
91 |
7.8 |
6.5 |
3.7 |
0.48 |
98 |
8.6 |
6.5 |
4.1 |
0.53 |
10.0 |
10.0 |
10.0 |
10.0 |
3.2 |
|
2MDX10-042-0816AN |
93 |
5.1 |
4.2 |
3.7 |
0.74 |
98 |
5.7 |
4.2 |
4.1 |
0.82 |
10.0 |
10.0 |
10.0 |
10.0 |
4.2 |
|
2MDX10-042-1020AN |
94 |
4.1 |
3.4 |
3.7 |
0.91 |
98 |
4.7 |
3.4 |
4.1 |
1.01 |
10.0 |
10.0 |
10.0 |
10.0 |
4.7 |
|
2MDX10-066-xxAN |
|||||||||||||||
|
2MDX10-066-0510AN |
92 |
12.1 |
6.6 |
6.0 |
0.75 |
99 |
13.3 |
6.6 |
6.6 |
0.83 |
12.0 |
12.0 |
12.0 |
12.0 |
3.2 |
|
2MDX10-066-0816AN |
95 |
7.7 |
4.1 |
5.7 |
1.16 |
100 |
8.9 |
4.3 |
6.6 |
1.29 |
12.0 |
12.0 |
12.0 |
12.0 |
4.2 |
|
2MDX10-066-1020AN |
95 |
6.3 |
3.3 |
5.8 |
1.43 |
100 |
7.2 |
3.5 |
6.6 |
1.59 |
12.0 |
12.0 |
12.0 |
12.0 |
4.7 |
|
2MDX10-102-xxAN |
|||||||||||||||
|
2MDX10-102-0510AN |
88 |
19.4 |
6.2 |
8.7 |
1.16 |
96 |
21.3 |
6.2 |
9.6 |
1.29 |
15.0 |
15.0 |
15.0 |
15.0 |
3.2 |
|
2MDX10-102-0816AN |
91 |
12.7 |
4.1 |
8.7 |
1.79 |
97 |
14.1 |
4.0 |
9.6 |
1.99 |
15.0 |
15.0 |
15.0 |
15.0 |
4.2 |
|
2MDX10-102-1020AN |
92 |
10.3 |
3.3 |
8.7 |
2.21 |
97 |
11.4 |
3.3 |
9.6 |
2.46 |
15.0 |
15.0 |
15.0 |
15.0 |
4.7 |
|
2MDX10-138-xxAN |
|||||||||||||||
|
2MDX10-138-0510AN |
89 |
26.1 |
6.3 |
11.9 |
1.58 |
97 |
28.7 |
6.3 |
13.1 |
1.75 |
17.0 |
17.0 |
17.0 |
17.0 |
3.2 |
|
2MDX10-138-0816AN |
92 |
17.0 |
4.1 |
11.9 |
2.43 |
98 |
18.7 |
4.1 |
13.2 |
2.70 |
17.0 |
17.0 |
17.0 |
17.0 |
4.2 |
|
2MDX10-138-1020AN |
93 |
13.8 |
3.3 |
11.9 |
2.99 |
99 |
15.4 |
3.3 |
13.2 |
3.33 |
17.0 |
17.0 |
17.0 |
17.0 |
4.7 |
2-stage TECs of 2MDX10 are the largest among all 2MDX types. The mix of serial and parallel commutation allows to increase the number of pellets on top stage and enlarge TEC cold side. Comparing with standard types 2MDX10 TECs have twice more pellets on top stage and higher TEC mechanical endurance. The balanced stage coefficient is achieved by pellets height adjustment. Such method allows to enlarge TEC cold side, increase the mechanical endurance of TEC second stage with more pellets and keep the optimal cooling performance without current or voltage increasing. 2MDX TE coolers are optimal for detector applications with large TEC cold side requirements. All 2MDX10 TECs are assembled using RoHS compliant Sn-Sb solder (Tmelt=230ºC) and meet Telcordia GR-486 standard requirements. The examples of the most common 2MDX10 thermoelectric types are listed in the table below. Detailed TEC drawings, 3D models, performance plots and estimations for particular application conditions are provided by request.
2MDX10 "HEAVY DUTY" TYPE 2-STAGE THERMOELECTRIC COOLERS
2MDX10 TE COOLERS ADVANTAGES
2MDX10 TE COOLERS KEY FEATURES
◻︎ Higher mechanical endurance of second stage
◻ Enlarged thermoelectric cooler cold side
◻ Unique mix of HD Technology and MX topology
◻ Wide range of manufacturing options available
◻ High-quality bulk BiTe material
◻ Accurate steam soldering technology
◻ RoHS compliant TE Coolers by default
◻ Telcordia GR-468 qualified TECs
2MDX10
Two-stage
TE Coolers
The key feature of all 2MDX thermoelectric coolers is their shape. These 2-stage TECs all have the same dimensions of cold and hot sides. There is no typical pyramidal shape here, like many standard multistage TECs have. All 2MDX TECs have the equal size of the hot, cold and the middle plate in between, which makes these TECs look quite like a cube. Such shape allows combining these TECs into stack configurations, with multiple thermoelectric coolers connected in serial or parallel and even in a mixed serial-parallel way. With 2MDX TECs you may create any required cold side surface area for large objects and get all the benefits of 2-stage thermoelectric cooler performance. On entry-level 2MDX TECs can be ordered separately for stack assembly later by customer. Or if required the configuration of TEC stack can be specified and ordered with all thermoelectric coolers already connected. On the master-level TEC stack can be manufactured upon request on a single union hot side ceramics plate (can be a subject of customization).
